Semiautomatic Hydraulic Drilling Lathe c7620

Semiautomatic Hydraulic Lathe C7620 -Used for bearings, pistons, gears, cardan joint and spare parts of car & motorcycle. The lathe is easy to regulate, better rigidity, cutting with great force. It is widely used to manufacture bearings, pistons, gears and in the production lines of cars and tractors. Due to adoption of structural steel rails set, it has better wearability and longer useful life. Due to adoption of hydraulic clamping mechanism, it is easy to load clamp workpiece. The cutting processing is decided by programmable controller(PLC). The lathes of models C7620/1 is fixed with hydraulic tailstocks. We can provide special orders for users, according to every technological requirements of parts to be present. Model NameDateTechnical SpecificationsC7620Semiautomatic Hydraulic LatheC7620/1Semiautomatic Hydraulic LatheMax. Cutting Dia & Length(mm)200x100200x100Main Spindle Speed Range(r/min)180 710(250 1000)180 710(250 1000)Main Spindle Taper HoleMorse 6Morse 6Knife Rest Work Feeding Speed(m/min)0.015-2(Stepless)0.015-2(Stepless)Knife Rest Fast Feeding Speed(m/min)3 53 5Rotatory Angel of Knife Rest±30 °c±30 °cTailstock Taper HoleMorse 4Main Motor Power(kw)7.5Outer Dimensions(mm)1800x1370x1400Lathe Weight(kg)1800
